ProSoft Technology RLX2-IHA User Manual

Reference RLX2 Series ♦ 802.11a, b, g, n
User Manual Industrial Hotspot
Page 128 of 161 ProSoft Technology, Inc.
May 8, 2013
8.7 RLX2-IHG Detailed Specifications
Radio
Frequency Band
(Varies by country)
802.11g:
2.412 GHz to 2.462 GHz (FCC)
2.412 GHz to 2.472 GHz (ETSI)
Wireless Standards
802.11g, 802.11i
Transmit Power (Programmable)
(varies by country)
24 dBm (250 mW) at 11 Mbps
24 dBm (250 mW) at 24 Mbps
21 dBm (125 mW) at 54 Mbps
Channel data rates (Modulation)
802.11g: (OFDM) Mbps
54, 48, 36, 24, 18, 12, 9, and 6
802.11b: (DSS) Mbps
11, 5.5, 2, and 1
Receiver Sensitivity (Typical)
-94 dBm @ 1 Mbps
-92 dBm @ 11 Mbps
-84 dBm @ 24 Mbps
-72 dBm @ 54 Mbps
Channel Selection
802.11g:
1 to 11 (FCC)
1 to 13 (ETSI)
Security
WPA2 - 802.11i with 128 bit AES-CCM
Legacy WPA TKIP, WEP support
MAC ID filter
Admin password
Physical
Enclosure
Extruded aluminum with DIN and panel mount
Size
14.8 x 11.8 x 3.8 cm (H x W x D)
5.82 x 4.64 x 1.48 in (H x W x D)
Shock
IEC 60068 2-6 (20 g, 3-Axis)
Vibration
IEC 60068 2-27 (5 g, 10 Hz to 150 Hz)
Ethernet Ports
One 10/100/1000 Base-T connector, shielded
RJ45
Antenna Port
(1) RP-SMA connector
Weight
1.1 lbs (499g)
Environmental
Operating Temperature
-40°C to +75°C (-40°F to +167°F)
Humidity
Up to 100% RH, with no condensation
External Power
PoE Injector
Power over Ethernet
10 Vdc to 24 Vdc
48 Vdc
802.3af Compliant
Average Power Consumption
Less than 7 Watts
Agency Approvals & Certifications
