1.2.2 LED Indicators
All radios have LED indicators on the front panel that indicate the status of the
radio while booting up and during operation. The LED states are summarized in
the following table:
Power
While booting up
When fully operational
RF Transmit
While transmitting over wireless
RF Receive
While receiving over wireless
Serial
When a serial cable is attached
Ethernet
When Ethernet data is being
transferred
Net
Alternates red and green if SD
card with new configuration inserted
Mod
Alternates red and green if SD
card with new configuration inserted
Signal Strength LEDs: SD card
inserted
 Alternates green and amber if
SD card with new configuration
inserted
Signal Strength LEDs: running in Client
or Repeater Modes
No Signal
Radio linked, Poor Signal
Radio linked, Fair Signal
Radio linked, Good Signal
Signal Strength LEDs: running in
Master Mode
No radios linked
 One or more radios linked
(right LED blinking).
  DFS Channel Availability
Check in progress (all LEDs blinking
Amber)
See section 5.3 for further details regarding the LED display for various
conditions.
