8.9 RLX2-IHW Detailed Specifications
Radio
Frequency Band
(Varies by country)
802.11b/g:
2.412 GHz to 2.462 GHz (FCC)
2.412 GHz to 2.472 GHz (ETSI)
802.11a:
5.150 GHz to 5.250 GHz (FCC/ETSI)
5.725 GHz to 5.850 GHz (FCC)
Wireless Standards
802.11a, 802.11b, 802.11g, 802.11i
Transmit Power (Programmable)
(varies by country)
Up to 50 mW without amplifier
Up to 500 mW with optional amplifier. (not
applicable for hazardous locations)
Channel data rates (Modulation)
802.11b: 11, 5.5, 2, 1 Mbps
(DSSS - BPSK, QPSK, CCK)
802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps (OFDM)
802.11a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps (OFDM)
Receiver Sensitivity (Typical)
-90 dBm @ 1 Mbps
-85 dBm @ 11 Mbps
-82 dBm @ 24 Mbps
-75 dBm @ 54 Mbps
Channels Selection
1 to 13 (802.11b/g)
36, 40, 44, 48, 149, 153, 157, 161, 165 (802.11a)
Security
WPA2 - 802.11i with 128 bit AES-CCM
Legacy WPA TKIP, WEP support
MAC ID filter
Admin password
Physical
Enclosure
Extruded aluminum with DIN and panel mount
Size
14.8 x 11.8 x 3.8 cm (H x W x D)
5.82 x 4.64 x 1.48 in (H x W x D)
Vibration
IEC 60068 2-6 (20g, 3-Axis)
Shock
IEC 60068 2-27 (5g, 10 Hz to 150 Hz)
Ethernet Ports
One 10/100/1000 Base-T connector, shielded
RJ45
Antenna Ports
(2) RP-SMA connectors
Weight
1.06 lbs (479g)
Environmental
Operating Temperature
-40°C to +75°C (-40°F to +167°F)
Humidity
Up to 100% RH, with no condensation
External Power
PoE Injector
Power over Ethernet
10 Vdc to 24 Vdc
48 Vdc
802.3af Compliant
Average Power
Less than 6 Watts
Agency Approvals & Certifications
