ProSoft Technology RLX2-IHA User Manual

Reference RLX2 Series ♦ 802.11a, b, g, n
User Manual Industrial Hotspot
Page 130 of 161 ProSoft Technology, Inc.
May 8, 2013
8.8 RLX2-IHNF Detailed Specifications
Radio
Frequency Band
Frequency
Channel
(Varies by country)
2.412 GHz to 2.462 GHz (FCC)
2.412 GHz to 2.472 GHz (ETSI)
1 to 11
1 to 13
5.150 GHz to 5.250 GHz (FCC/ETSI)
5.250 GHz to 5.350 GHz (ETSI)
5.470 GHz to 5.580 GHz (ETSI)
5.680 GHz to 5.700 GHz (ETSI)
5.725 GHz to 5.850 GHz (FCC)
36 to 48
52 to 64
100 to 116
136 to 140
149 to 165
Wireless Standards
802.11n, 802.11h, 802.11i,
802.11a, 802.11g (Legacy)
Transmit Power
(Programmable)
*Subject to Regional
Regulatory Limits
22 dBm @ MCS0, MCS8 (802.11an/gn)
17 dBm @ MCS7, MCS15 (802.11an/gn)
22 dBm @ 6 Mbps (802.11a/g)
17 dBm @ 54 Mbps (802.11a/g)
Antenna Impact:
3 Antennas/ MIMO: Use values above
2 Antennas: Subtract 3 dB from values above
1 Antenna: Subtract 5 dB from values above
Channel data rates
(802.11n)
MCS0 through MCS15,
1 Channel or 2 Channels with 1 Stream or 2 Streams
1 Channel
2 Channels
Rate
Streams
7 Mbps
15 Mbps
MCS0
1 Stream
72 Mbps
150 Mbps
MCS7
14 Mbps
30 Mbps
MCS8
2 Streams
144 Mbps
300 Mbps
MCS15
Channel data rates
(802.11a/g)
802.11a/g:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
Receiver Sensitivity
(Typical)
-92 dBm @ MCS0, MCS8 (802.11an/gn)
-70 dBm @ MCS7, MCS15 (802.11an)
-74 dBm @ MCS7, MCS15 (802.11gn)
-92 dBm @ 6 Mbps (802.11an/gn)
-74 dBm @ 54 Mbps (802.11a)
-78 dBm @ 54 Mbps (802.11g)
Security
WPA2 Personal – 802.11i AES w/ Passphrase
Legacy WPA TKIP, WEP support
MAC ID filter
Physical
Enclosure
Extruded aluminum with DIN rail mount
Size
14.8 x 11.8 x 3.8 cm (H x W x D)
5.82 x 4.64 x 1.48 in (H x W x D)
Shock
IEC 60068 2-6 (20g, 3-Axis)
Vibration
IEC 60068 2-27 (5g, 10Hz to 150Hz)
Ethernet Port
One 10/100 Base-T connector, shielded RJ45
IEEE 802.3, 802.3u, 802.3x
Antenna Port
(3) RP-SMA connector
Personality Module
Industrial SD Memory Module
Weight
1.1 lbs (499 g)
