RLX2 Series ♦802.11a, b, g, n Detailed Radio Configuration / Diagnostics
Industrial Hotspots User Manual
ProSoft Technology, Inc. Page 57 of 161
May 8, 2013
6.1.2 Address table
The Address Table shows the port through which each MAC address is
connected, along with the age in seconds since the radio last saw a packet from
this MAC address.
Field
Description
Radio MAC
MAC address of the selected radio. The MAC ID is also printed on the
side of the radio.
Show Addresses for the
Following
Dropdown list to filter the address list. Options are:
Devices Out Ethernet Port
Directly Linked Radios/Clients
Devices beyond Direct RF Links
When the table is filtered to show only Directly linked radios/clients, an
additional RSSI column is listed, showing the Received Signal Strength
from each radio or client linked to the radio.
Number of Rows to
Display
Selects the number of MAC addresses to display on this page. Use the
Next and Prev buttons to scroll through the available MAC addresses.
Index
Position in the list. Each page shows up to 10 devices. Use the Next
and Previous buttons to move up and down through the table.
MAC Address
MAC address for the device.
Connection
Connection type
Age (s)
Length of time (in seconds) since the radio last saw a packet from this
MAC address
Top
Click the Top button to see the top of the table. The radio will display
updated data in the table entries.
Next / Prev
If the table has more MAC addresses than it can display in the window,
use the Next and Prev buttons to move up and down through the table.
Refresh
Updates the table.
