Bitmapped value that indicates which files are not present
Bit 0: Problem with PDPMV1.CFG file
Bit 1: Not used
Bit 2: Problem with PDPMV1.DDB file
Bit 3: Problem with PDPMV1.XML file
Bits 4 to 15 not used.
If this word has a value other than 0, the CFG ERR LED on the
module will be illuminated.
Number of message in the in mailbox queue
Number of message in the out mailbox queue
Number of message in the alarm queue
Last out mailbox message ID
processed from output image
Last out mailbox message ID processed from output image
Current in mailbox control index
Current in mailbox control index
Current alarm control index
Current alarm control index
Index of Output image to receive (1 to 4 for data, 0 or -1 if no
data)
Block index of -1 or 0 for status block
Output Data Block (Block ID = 1 to n)
This block contains the PROFIBUS output data to be sent from the processor to
the module.
Output Data Block Format (Output Image)
You can find the contents of the Output Data Block (Output Image) in the
MVI56PDPMV1.Output user controller tags in RSLogix.
Block number of this write block 1 to n
Computed for PROFIBUS Config
Computed for module data
When the module first starts up or recognizes an initialization of the
processor, it will compare the values of the two CRC’s in the input and
output images. If either one of the CRCs do not match, the module will
be placed in Stop mode. If each set matches, the module will be
placed in Operate mode.
PROFIBUS output data transferred to the PROFIBUS slaves
