9. OUTPUTS / INPUTS OF THE PAA20+
The contacts order in the connectors and the internal circuitry of the PAA20 +
outputs as shown on the following schemes and pictures:
9.1. OUTPUT 1 CONNECTOR:
Figure 9.1A
Figure 9.1B
