AP D.3.3 PROGRAMMING
The programming feature is only for Proyecson’s certified personal. If you are
not trained by Proyecson do not use this feature.
AP D.3.3.1 ABSTRACT:
PAA20+ firmware is composed by three modules:
1. Bootloader: it manages the device boot and let the upgrade by
Ethernet.
2. Main program: Once bootloader finishes, The PAA20+ program starts
and works normally (.hex file)
3. Website: Web pages saved in an external memory which the user can
config and test the device. (.bin file)
The writing order in the different memories of the device is the one in the
previous list.
The only way
AP D.3.3.2 REQUIREMENTS:
The following tools are needed to do it:
1. A computer connected directly to the device and configured at the
same subnetwork. (The IP in the BootLoader PAA20+ will be always
10.0.0.180)
2. An Ethernet cable.
3. *.hex y *.bin needed files to upgrade.
INSTALLATION MANUAL: PAA20+ V 2.0 (10/2021) 129
