12. TECHNICAL DRAWS, LABELS, DIMENSIONS AND WEIGHT

Dimensions and Weight

Dimensions: 483 x 128.5 x 44 mm.

Weight: 2 kg.

Example of device identification and power requirements label:

INSTALLATION MANUAL: PAA20+ V 2.0 (10/2021) 119
