8.2 DOREMI DCP AND SHOW VAULT SERIES SERVERS SET-UP.
This manual is baseed on the Doremi software version 2.0.10-0, other
versions may differ.
You must add the device in the server, indicating the setup of the unit you
want to control, before initiating a connection to the PAA20+.
8.2.1 Adding the PAA20+ to Doremi DCP and SV servers: Ethernet
interface.
To add the PAA20+ as Ethernet device in DCP2000, DCP2K4 and ShowVault
Doremi servers, follow the next steps:
1. Turn on the server.
2. Open the “Device Manager”, by accessing it through the Menu ->
Doremi Labs Inc. -> Device Manager.
3. Click on the icon “Add”.
4. On the appearing pop-up window, select the device “Raw” as shown in
the Figure 8.2.1A.
Figure 8.2.1A
INSTALLATION MANUAL: PAA20+ V 2.0 (10/2021) 47
