6.10 CONNECTION TO CHRISTIE IMB S2 SERVER OVER ETHERNET
The connection of the PAA20+ to the Christie IMB S2 server must be done
through the Ethernet port.
The PAA20+ must be added to IMB S2 server as a new device and
send/receive commands configured as explained throughout this manual.
See the interconnection diagram on the following picture:
INSTALLATION MANUAL: PAA20+ V 2.0 (10/2021) 22
