Proyecson PAA20+ - Page 4

8.3.4 Setting up input cues for Doremi, Dolby and NEC IMS servers with xml lib.....74
8.4 BARCO ALCHEMY ICMP SERVER SET-UP...........................................................77
8.4.1 Adding the PAA20+ to Barco Alchemy ICMP servers: Ethernet interface.........77
8.4.3 Setting up the output cues for Barco Alchemy ICMP servers using xml library. 84
8.4.4 Setting up the PAA20+inputs for Barco Alchemy ICMP servers......................87
8.5 GDC SERVER SET-UP.....................................................................................91
8.5.1 Adding the PAA20+ to the GDC server: Ethernet interface............................91
8.6 QUBE SERVER SET-UP...................................................................................99
8.6.1 Adding the PAA20+ to the Qube server: serial interface...............................99
8.6.2 Configure the Qube inputs on the PAA20+................................................102
8.7 DATASAT SERVER SET-UP............................................................................104
8.8 CHRISTIE IMB S2 SERVER SET-UP................................................................105
8.8.1 Configure the Christie IMB S2 automation for the PAA20+..........................105
9. OUTPUTS / INPUTS OF THE PAA20+.............................................109
9.1. OUTPUT 1 CONNECTOR:.............................................................................109
9.2 OUTPUT 2 CONNECTOR:..............................................................................110
9.3 OUTPUT 3 CONNECTOR:..............................................................................111
9.4 INPUT CONNECTOR:....................................................................................112
9.5 EXAMPLES OF INPUT CONNECTION:..............................................................113
9.5.1 INPUT WITH A NEGATIVE COMMON:........................................................113
9.5.2 INPUT WITH A POSITIVE COMMON:.........................................................114
9.6 SERIAL PROT PIN-OUT.................................................................................115
10 FIRMWARE VERSIONS..................................................................116
11. ELECTRICAL REQUIREMENTS.......................................................118
12. TECHNICAL DRAWS, LABELS, DIMENSIONS AND WEIGHT...........119
APPENDIX A: SERIAL COMMANDS FOR DOLBY...................................120
APPENDIX B: COMMANDS FOR DOREMI AND IMS SERVERS...............122
APPENDIX C: TABLE FOR TCP/IP CHANGES ANNOTATION.................124
APPENDIX D: PAA20+ TESTER AND PROGRAMMER SOFTWARE.........125
AP D.1 HARDWARE REQUIREMENTS....................................................................125
AP D.2 INSTALLATION.......................................................................................125
AP D.3 USE......................................................................................................126
AP D.3.3.1 ABSTRACT:...................................................................................129
AP D.3.3.2 REQUIREMENTS:...........................................................................129
APPENDIX E: COMMANDS FOR GDC SERVERS....................................130
INSTALLATION MANUAL: PAA20+ V 2.0 (10/2021) 4
