Config Backup: Using this field you can export the actual PAA20+

configuration to an *.cfg file.

Reset: This button applies a factory default reset to the PAA20+. This action

implies an IP configuration reset.

INSTALLATION MANUAL: PAA20+ V 2.0 (10/2021) 42
