PTW MP3-PL - Figure 9: Mounting the B-Axis

MP3-PL Therapy Beam Analyzer T41050
Operating Manual – Assembly of the System
D850.131.05/01 en
25
Figure 9: Mounting the B-axis
1 Gear box B
2 Screw M5x16 (2x)
3 Conical bolt
4 Slider B
5 B-axis
6 Supporting profile
7 Supporting rolls
8 Screw M3x12 (2x)
9 Cable holder (2x)
10 Motor cable B/C
11 Slider A
12 A-axis
13 Crosshairs
1
13
4
10
7
2
5
6
3
12
9
8
11
