MP3-PL Therapy Beam Analyzer T41050
Operating Manual – Installation of the System for Measurement
D850.131.05/01 en
29
Figure 12: Vertical mounting of the 3D-detector-
block with 24 PinPoint chambers
1 3D-detectorblock T21003.1.001
2 Holder T21003.1.010
3 Screw M4x10 (3x)
4 Clamping screw (2x)
Figure 13: Horizontal mounting of the 3D-detector-
block with 24 PinPoint chambers
1 3D-detectorblock T21003.1.001
2 Holder T21003.1.010
3 Clamping screw (2x)
4
1
3
2
3
1
2
