MP3-PL Therapy Beam Analyzer T41050

Technical Manual – Order Information

D850.131.05/01 en

7 Order Information

MP3-PL basic equipment

MP3-PL Perspex tank with

moving mechanism

TBA junction box

MP3-PL accessories

Cover, ball-shaped screwdriver SW 3,

hexagon head screwdriver (SW 2.5, 3, 4, 5), circular bubble level,

Fat Staburags NBU 12K, anti-corrosion fluid

T41050

TBA CONTROL UNIT

T41013

TBA CONTROL PENDANT

T41031

TBA control cable

T43164/K1-4

TBA motor cable

T43164/K2-4

SCANLIFT (incl. control unit)

T41024

MP3-M positioning device, swiveling

T41022.1.021

Chamber cable holding device for MP3-PL

T20015.1.200

Detector connection box 12 x M

T16007

PinPoint chamber 0.03 cm³

TM31015

3D-detectorblock

T21003

MULTIDOS

T10004

MULTIDOS connection cable, with HV, 6 m

T26011-6

Interface cable RS232

L178012

COM-Server (RS232-TCP/IP Interface), 4 Port

L991272
