PTW MP3-PL - Figure 10: Mounting the C-Axis

MP3-PL Therapy Beam Analyzer T41050
Operating Manual – Assembly of the System
26
D850.131.05/01 en
Figure 10: Mounting the C-axis
1 Catch pin
2 Groove
3 Slider C
4 Axis C
5 Threaded control shaft
6 Slider B
7 Centering bore
8 Centering shoulder
9 Screw M4x10 (4x)
10 Axis B
3
10
1
7
4
5
8
9
6
2
