MP3-PL Therapy Beam Analyzer T41050
Technical Manual – Technical Specifications
Technical Manual
6 Technical Specifications
Only values with specified tolerances or limits are guaranteed. Values without tolerances are for information
purposes only.
MP3-PL Therapy Beam Analyzer, T41050
computer-controlled system for measuring dose distributions
(depth dose curves and profiles) in order to check the emitted
irradiation of particle accelerators (such as a cyclotron or syn-
chrotron)
Electromagnetic compatibility
suitable for operation in an industrial electromagnetic envi-
ronment according to IEC 61326-1
Perspex tank
Material
Wall thickness
side walls and bottom
window
Outside dimensions
Inside dimensions
Window dimensions
Window position
Deflection of the window
with filled tank
Max. water quantity
Weight
Mounting of special accessories
PMMA
18 0.15 mm
5 0.05 mm
630 1.3 mm x 520.5 1.15 mm x 632 1.3 mm
594 1.0 mm x 502.5 1.0 mm x 596 1.0 mm
250 0.2 mm x 250 0.2 mm
middle of moving range of C-axis and 217.5 mm from the tank
surface in direction of B-axis
< 1.0 mm
approx. 170 l
approx. 44 kg
(Perspex tank with moving mechanism and junction box)
in front of the window, max. 15 kg
