MP3-PL Therapy Beam Analyzer T41050
Technical Manual – Technical Specifications
48
D850.131.05/01 en
Moving mechanism
Moving range A-axis
Moving range B-axis
Moving range C-axis
Reproducibility
Positioning accuracy
Step interval
500 mm
408.5 mm
500 mm
0.1 mm
0.5 mm
0.1 mm
Max. cable length
40 m (between control unit and water phantom)
Positioning device
Adjustments
Vertical with a travel of
Horizontal in the plane
Pivoting around vertical axis
Swiveling to positions
Support plate material
Outside dimensions
Overall height in middle position
Outside dimensions of the support plate
Weight
 10 mm
 10 mm
approx.  1°
0°,  45° and  90°
5 mm aluminum, anodized
671 mm x 669 mm
117.5 mm
636 mm x 634 mm
approx. 25 kg
Effect of electromagnetic disturbances
no effect
Rated range of use
Temperature
Relative humidity
Atmospheric pressure
Maximum operating altitude
(+10 ... +40) °C / (50 … 104) °F
(10 ... 80) %, no condensation
(max. 20 g/m³ absolute humidity)
(700 ... 1060) hPa
3000 m above sea level
Environmental conditions for transport and
storage
Temperature
Relative humidity
Atmospheric pressure
(-20 ... +60) °C / (-4 … 140) °F
(10 ... 85) %, no condensation
(max. 20 g/m³ absolute humidity)
(600 ... 1200) hPa
