3 Installation of the System for Measurement
NOTE
You can use the supplied tools to install the sys-
tem.
All components must be of the same connection
system (M).
3.1 Quickstart (Workflow)
 Position SCANLIFT (with mounted positioning
device, chamber cable holding device and Per-
spex tank).
 Mount the measuring detector or detectors on
the moving mechanism according to section 3.2.
 Connect the measuring detector or detectors
according to section 3.3.
 Mount the reference detector and connect it
according to section 3.4.
 Mount further measuring equipment:
 Inhomogeneous phantom T43031 according
to section 3.5
 Hemisphere T41029.3.231 according to sec-
tion 3.6
 Wedge T41029.1.220 according to sec-
tion 3.7
 Film holding device T40040 according to sec-
tion 3.8
 Align the Perspex tank by using the laser system
of the accelerator.
 Connect SCANLIFT to the Perspex tank accord-
ing to section 3.9
 Fill the Perspex tank with distilled water (refer to
section 3.10).
 Adjust the water level by means of the adjusta-
ble legs (by comparing the water line with the
horizontal lines or by using the circular bubble
level).
 Check the height setting again in this position
and, if necessary, correct it by means of the ad-
justing screws.
 Connect all cables between TBA CONTROL
UNIT, TBA CONTROL PENDANT and Com-
Server according to section 3.11.
 Connect the following devices with the power
cord to the power line:
– TBA CONTROL UNIT
– MULTIDOS
– SCANLIFT
– COM-Server
CAUTION
Inaccurate orientation of the measuring detectors
or detector.
Erroneous Measurement!
Observe the effective points of measurement of
the detectors specified in the respective user
manual.
 Position the measuring detector or detectors by
using the TBA CONTROL PENDANT and check
or set the limits and zero point.
