QubicaAMF 400288005 User Manual

System components BES X installation manual
2 P/N: 400288005; Rev: L, 09/21
• Up to 50 m (up to 150 ft.): one AWG-24 Cat. 5e network cable;
• More than 50 m (more than 150 ft.): one solid AWG-23 Cat. 6 cable.
These cables are provided by QubicaAMF.
1.1.2 5HD-HUB label description
1
4
6
3
2
5
The image above shows the label located on the side of the 5HD-HUB unit.
1. Manufacturer (QubicaAMF Europe S.p.A.);
2. Part number (P/N: 288250025-02);
3. List of certifications (CE certification, Hi-Pot Tested);
4. Name of the unit (5HD-HUB);
5. Electrical notes (100-240 V; 1.3-0.6 A; 50/60 Hz);
6. Serial number with bar code.
1.1.3 5HD-HUB Rev.2 label description
1
4
6
3
2
5
7
The image above shows the label located on the side of the 5HD-HUB Rev.2 unit.
1. Manufacturer (QubicaAMF Europe S.p.A.);
2. Part number (P/N: 288250025-01);
3. List of certifications (CE certification);
4. Name of the unit (5HD-HUB);
5. Electrical notes (100-240 V; 1.3-0.6 A; 50/60 Hz);
6. Serial number with bar code.
7. Revision of the unit (Rev.2)

QubicaAMF 400288005 Specifications

General

Brand	QubicaAMF
Model	400288005
Category	Security Sensors
Language	English
