13
ESP-LXME Controller
Section B - Basic Programming
Program Select Switch
Always begin programming by setting the Program Select switch to
the desired program.
Four independent Programs, A, B, C and D are available in the ESP-
LXME controller. Multiple programs allow you to set watering schedules
to meet dierent requirements for plant materials, soils, slopes, and
shady or sunny areas. Programs can operate simultaneously with
the only limitation being the number of stations you program to run
simultaneously.
Select Program
On the controller front panel, slide the Program Select switch under
the A, B, C, or D, then begin programming.
Program
Select
Switch
NOTE: When programming the controller, any program-specic
information you enter, such as start times or watering days, will
aect only the selected program.
Weather Sensor Bypassed/Active Switch
A weather sensor is not required for the ESP-LXME controller, but can
increase functionality by allowing you to prevent or pause irrigation
based on changing weather conditions.
You can set the controller to ignore or obey input from one supported
weather sensor, which connects to the LXME base module via a separate
wired or wireless connection. See Section H, Local Weather Sensor for
more details.
Bypass or Activate Weather Sensor
On the controller front panel, slide the Weather Sensor switch to
Bypassed (to ignore) or Active (to obey).
Weather
Sensor
Switch
