ESP-LXME Controller
G
Once wiring is completed, ll top of conduit with waterproof
caulking to prevent insect intrusion into the controller cabinet.
7
Connect Local Weather Sensor
The ESP-LXME can accept input from a single weather sensor wired
directly to the controller or through a wireless receiver.
A local weather sensor can be bypassed with the sensor bypass switch
on the controller front panel.
To Enable a Local Weather Sensor:
A
On the controller front panel, slide the Weather Sensor switch to
Active.
a

NOTE: Follow the sensor manufacturer’s instructions to correctly
install and make wire connections to the sensor. Ensure the sensor
installation is in compliance with all local codes.

Rain Bird ESP-LXME Specifications

General

Programs	4 independent programs
Controller Type	Modular
Station Run Time	1 minute to 12 hours
Enclosure Rating	NEMA 3R
Enclosure	Wall-mount
Power Source	120 VAC
Water Management	Seasonal Adjust
Sensor Compatibility	Rain Sensor
Communication	Optional
Battery Backup	Lithium
Watering Schedule	Odd/Even day, Cyclical
