44
ESP-LXME Controller
Set SimulStations
TM
for Controller
NOTE: The LXME SimulStations settings will supersede program-
level settings. For example, if the LXME setting is 2 but three
programs have a maximum setting of 4, then only 2 stations will
be allowed to run simultaneously.
Turn the controller dial to Advanced Settings.
A
The Advanced Settings screen appears. Press the Down Arrow
button to select SimulStations; then press Next.
B
The SimulStations screen appears. Press the Down Arrow button
to select LXME SimulStations; then press Next.
1 2
C
The ESP-LXME Maximum Number of SimulStations screen
appears. Press the + and – buttons to set the maximum number of
irrigation stations (from 1 to 5) that can operate simultaneously;
then press Next.
D
Press the + and buttons to set the maximum number of non-
irrigation stations (from 1 to 5).
3 4
NOTE: The Non-Irrigation SimulStations setting is used to
congure the maximum number of Non-Irrigation stations
that can operate simultaneously and allows you to balance the
number of Irrigation and Non-Irrigation stations that can operate
simultaneously.
