58
ESP-LXME Controller
Connect Flow Sensor
A
Install the ow sensor in the eld according to the manufacturer’s
instructions, and run the ow sensor wire to the ESP-LXME
controller.
B
Route the ow sensor wire through the knockout on the bottom
of the controller.
C
Connect the ow sensor wire to the Flow + and Flow - inputs. When
nished, tug gently on the wires to make sure the connections are
tight.
NOTE: For Rain Bird FS-Series ow sensors, connect the red
sensor wire to the red (+) terminal and the black sensor wire to
the grey (-) terminal.
2
3
1
NOTE: The blue light on the FSM-LXME Flow Smart Module will
ash as ow is measured by the ow sensor.
Module Programming
Setup Flow Sensor
Turn the controller dial to Module Programming.
A
The Smart Module PGM screen appears with Flow Smart Module
selected; press Next.
B
The Flow Smart Module PGM screen appears with Flow Sensor
Setup selected; press Next.
1 2
NOTE: If a FSM-LXME Flow Smart Module is not installed, the
screens displayed on pages 58 through 72 will not be displayed.
To Next Page
