P/N 016-0171-277 Rev. L 99
VIPER PRO CALIBRATION AND OPERATION
ROUTINE OPERATION
ENGAGING SMARTRAX
FIGURE 39. SmarTrax System Engaged
The steering wheel icon in the lower right corner of the Viper Pro screen indicates whether the SmarTrax system is
engaged or disengaged. The steering wheel is green when the system is enabled and gray when it is not.
NOTE: The operator liability waiver must be accepted before the SmarTrax system can be enabled for
operation.
The SmarTrax steering may also be engaged using the following methods:
• Tap the foot switch or rocker switch to engage SmarTrax features without touching the Viper Pro display.
• Press the SmarTrax on-screen status button to engage the SmarTrax during field operation.
UPDATING THE NODE
Refer to the Viper Pro Installation & Operation Manual (P/N 016-0171-122) for instructions on updating the node
software.
