CHAPTER 3
CR7 CALIBRATION AND
OPERATION
BUTTONS AND DEFINITIONS
The following are common status or mode information which may be displayed while the SmarTrax system is
engaged.
Display Message
The SmarTrax node is detected, but no guidance line
had been set or there is an error in the system. The
operator may need to accept responsibility for the
operation of the SmarTrax system.
SmarTrax is not engaged, and there are no errors
detected in the system.
SmarTrax is engaged, with no errors detected.
SmarTrax is engaged, but a system warning is detected.
SmarTrax is not engaged, and a system error is detected.
Previous - Returns the CR7 display to the previous
screen in the setup process.
Next - Saves the changes made to the SmarTrax system
and proceeds to the next step in the setup process.
