CHAPTER 3
26 SmarTrax™ Calibration & Operation Manual
NOTE: To ensure the calibration is successful, the number of starts and stops during the calibration process
should be limited. If it is necessary to pause the calibration process, turn the steering wheel or tap the
foot/enable switch. Tap the foot/enable switch again to resume calibration.
FIGURE 23. Steering Calibration Screens
1. Position the machine in an open space with several acres of smooth ground available to perform the machine’s
steering calibration.
WARNING
The machine’s wheels will turn automatically. Be
sure the area around the vehicle is clear of
people and equipment before engaging the
steering system.
NOTICE
The calibration of the machine’s steering system
should be performed in a field or other large,
open space and during conditions similar to
normal vehicle operation.
If the ground or surface is slippery, muddy, or
freshly tilled, the SmarTrax system may learn
incorrect steering responses for normal
operating conditions.
Ensure that the machine’s hydraulics are
operating properly and there are no other
mechanical issues that may affect the
performance of the SmarTrax system.
