4
P/N 016-0171-277 Rev. L 41
VIPER 4/4+ CALIBRATION AND OPERATION
FIGURE 5. Serial Device Setup Screen
1. Select Edit.
2. Select Serial Devices.
3. Press the Retry button in the bottom-right corner of the screen. The following screen will appear:
4. Verify that the SmarTrax and 600S are listed in the Serial Device Setup screen.
NOTE: If SmarTrax and 600S is not visible in the list, inspect cable connections to ensure they are installed
securely, then press the Retry icon again. Refer to Chapter 7, Troubleshooting beginning on page 133
for further information.
5. Press Accept.
