CHAPTER 5
86 SmarTrax™ Calibration & Operation Manual
1. Drive the machine forward 33 feet and park on a flat surface.
NOTE: The machine must detect a forward motion prior to calibration to determine which direction is
forward.
FIGURE 20. Enhanced Tilt Calibration Wizard
2. Follow the on-screen instructions to begin the calibration process.
FIGURE 21. Machine’s Rear Axle Marked Before Enhanced Tilt Calibration
3. Place flags or markers on the outside of each rear wheel aligned with the axle.
4. Select Next.
