7.6 Autopilot status symbols

The autopilot status is indicated in the databar.

Symbol Description

Autopilot is in Standby mode.

Autopilot is in Track mode.

Autopilot is in Auto mode.

No autopilot detected.

Autopilot alarm active.

Dodge mode is active.

Fish mode is active.

Autopilot calibration.

Symbol Description

Power steering active.

Wind Vane mode is active.

Using autopilot control

107
