Icon Description
Aid To Navigation virtual target: ON position.
Aid To Navigation virtual target: OFF position.
Standard AIS symbols are used to indicate whether the target is
dangerous, lost, or selected.
Note: You can NOT display vectors for an AToN target (activate).
Note: You can NOT add an AToN target to the Buddy List.
Displaying AIS data for AToN targets
In the chart or radar application, with the AIS layer enabled:
1. Move the cursor over the relevant Aid To Navigation (AToN)
target.
The softkeys change to show the AToN options.
2. Select the VIEW FULL AIS DATA softkey.
10.14 Land base station targets
With an AIS unit connected by NMEA 0183 or SeaTalk
ng
your
system can display land base station targets.
Land base station targets represent shore-based stations that have
been equipped with AIS technology. They broadcast information
such as their location, approximately every 10 seconds.
These stations may also be programmed to provide other navigation
safety information, for example, meteorological and hydrological
data. However, not all information broadcast by land base station
targets is currently supported by your multifunction display.
The following land base station target information is supported by
your multifunction display, and will be shown in the chart or radar
applications when you position the cursor over a land base station
target and press the VIEW FULL AIS DATA softkey:
• Name.
• Type.
• Position.
• Status.
• Off / On position.
• MMSI.
• Dimensions.
• CPA.
• TCPA.
• Last seen.
In the chart and radar applications land base station targets are
shown as:
Icon Description
Land base station target: ONLINE.
162 E-Series Widescreen User reference
