3. Use the TROPICAL STATEMENTS, MARINE WARNINGS,
MARINE ZONE FORECASTS, or WATCHBOX WARNINGS
softkeys to select the required weather reports.
6.12 Chart presentation
The chart has a number of presentation options which affect the
level of detail, types of objects and aspects of its operation.
The presentation options available are:
• Sync — Synchronize the radar and chart scales.
• Chart detail — Set the level of object detail shown on the chart.
• Chart type — Select shing charts (if supported by your chosen
chart supplier).
• View — Toggle 2D and 3D perspective view.
Accessing chart presentation options
In the chart application:
1. Select the PRESENTATION softkey.
2. Use the softkey toolbar to set the required options.
Multiple chart synchronization
You can synchronize the heading, range, and position information
across multiple chart views and networked displays (SeaTalk
hs
).
When chart synchronization is enabled:
• It is indicated by “Chart Sync” in the chart application status bar.
• Some softkey functions are not available with this feature, and
are “grayed-out”.
• Any changes made to the heading, range or position in any chart
instance will be reected in all other chart instances.
Note: When the 2D and 3D chart views are synchronized, the
Motion Mode is always Relative Motion.
Synchronizing multiple chart instances
In the chart application:
1. Select the PRESENTATION softkey.
90 E-Series Widescreen User reference
