11A-41
TOP AND FRONT OF ENGINE
Timing belt: Removal - Refitting
K9K
11A
a Refit the camshaft pulley hub lower bolt (34) .
a Tighten the camshaft pulley hub bolts.
a Remove:
-the (Mot. 1489),
-the (Mot. 1430).
109045
