17B-15
PETROL INJECTION
Crankshaft position sensor: Removal - Refitting
K4M
17B
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove the front engine cover.
a Remove:
-the engine undertray bolts,
-the engine undertray.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Disconnect the crankshaft position sensor connector
(1) .
Essential equipment
diagnostic tool
Tightening torquesm
crankshaft position sen-
sor bolts
8 N.m
JH3
TL4
JH3
135919
