10A-16
ENGINE AND CYLINDER BLOCK ASSEMBLY
Crankshaft seal at gearbox end : Removal - Refitting
K9K
10A
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Fit the end piece (1) of the (Mot. 1579) (2) .
a Position the jaws (3) of the (Mot. 1579) on the
crankshaft (4) .
a Push the tool (Mot. 1579) until contact is made
between the ends (5) of the jaws and the crankshaft
seal.
a Move the jaws away by tightening the bolt (6) using
an open-jawed spanner.
105259
105265
105266
105267
