11A-91
TOP AND FRONT OF ENGINE
Rocker cover: Removal - Refitting
K9K
11A
bracket,
-the oil vapour rebreathing valve bracket.
a Disconnect the brake servo pipe from the vacuum
pump.
a Remove:
-the nuts (9) of the oil vapour rebreathing valve,
-the oil vapour rebreathing valve,
-the oil vapour rebreathing valve seal from the oil
vapour rebreathing valve.
a Unclip the injector rail protector cover at (10) .
a Remove:
-the injector rail protector cover bolt (11) ,
-the injector rail protector cover nut (12) ,
-the injector rail protector cover.
a Unclip the injector rail protector cover at (13) .
a Remove:
- the injector rail protector cover bolt (14) ,
- the injector rail protector cover.
K9K, and 832
134699
K9K, and 830
135878
