11A-93
TOP AND FRONT OF ENGINE
Rocker cover: Removal - Refitting
K9K
11A
a Unclip the fuel return rail from the rocker cover at
(18) .
a Disconnect the oil vapour rebreathing pipe from the
rocker cover.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Remove:
- the rocker cover bolts (19) ,
- the rocker cover,
- the rocker cover seal.
a Remove:
- the rocker cover bolts (20) ,
K9K, and 830
135860
K9K, and 832
K9K, and 832
135489
K9K, and 830
135876
