11A-140
TOP AND FRONT OF ENGINE
Cylinder head: Removal - Refitting
K9K
11A
a Remove:
-the rocker cover bolts (14) ,
-the rocker cover.
a Remove:
-the rocker cover bolts (15) ,
-the rocker cover.
a Remove:
- the dipstick,
- the dipstick guide bolts (16) .
a Move aside the dipstick guide.
a Disconnect the vacuum pipe (17) of the turbochar-
ging pressure regulation solenoid valve from the va-
cuum pump.
a Unclip the hose of the turbocharging pressure regu-
lator solenoid valve from the cylinder head.
K9K, and 832
135489
K9K, and 830
135876
134703
134704
