12B-27
TURBOCHARGING
Turbocharger oil pipe: Removal - Refitting
K9K, and 830 or 832
12B
REFITTING THE TURBOCHARGER OIL
RETURN PIPE
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: turbocharger oil
pipe seal (10,09,03,05).
a Lubricate the new turbocharger oil return pipe O-ring
with clean engine oil.
II - REFITTING OPERATION FOR PART
CONCERNED
a Fit a new turbocharger oil return pipe equipped with
a new seal.
a Refit the turbocharger oil return pipe bolts.
a Torque tighten the turbocharger oil return pipe
bolts (12 N.m).
III - FINAL OPERATION
a Refit the catalytic converter (see 19B, Exhaust, Ca-
talytic converter: Removal - Refitting, page 19B-
17) .
a Refit the lower engine tie-bar (see 19D, Engine
mounting, Lower engine tie-bar: Removal - Refit-
ting, page 19D-33) .
a Refit the engine undertray.
a Connect the battery (see Battery : Removal - Refit-
ting) (80A, Battery).
K9K, and 830
