13B-135
DIESEL INJECTION
Leak flow from injectors: Check
K9K, and 834
13B
a Refit:
-the retaining bracket of the intermediate air pipe
between the turbocharger and the intercooler,
-the bolt of the retaining bracket of the intermediate
air pipe between the turbocharger and the intercoo-
ler,
-the clip of the turbocharger air outlet pipe.
a Clip the intermediate air pipe between the turbochar-
ger and the intercooler onto the turbocharger air out-
let pipe.
a Refit:
-the bolt of the intermediate air pipe between the
turbocharger and the intercooler,
-the nut of the intermediate air pipe between the tur-
bocharger and the intercooler,
-the engine cover.
