13C-9
PREHEATING
Heater plugs Removal - Refitting
K9K, and 830
13C
a
a Unscrew the heater plugs (4) using a 10 mm long ra-
dio socket connected to a universal joint or a hinged
wrench for heater plug.
a Use a hose to unscrew the heater plugs completely
(4) .
a Remove the heater plugs.
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Without tightening, fit the heater plugs using the ho-
se.
a Torque tighten the heater plugs (15 N.m).
a Connect the connector for each heater plug.
II - FINAL OPERATION
a Refit the injector rail protector cover.
a Clip on the injector rail protector cover.
a Refit:
-the turbocharger air outlet pipe (see 12B, Turbo-
charging, Intercooler air inlet pipe: Removal -
Refitting, page 12B-41) ,
- the engine cover.
135860
Note:
If the heater plugs are seized, use the tool for
removing heater plugs (see Heater plug remo-
val tool: Use) (Technical Note 5197A, 06A, Too-
ling).
