14A-29
ANTIPOLLUTION
Exhaust gas recirculation assembly: Removal - Refitting
F9Q
14A
a Remove the tools (Ms. 583) from the exhaust gas
cooler hoses.
a Connect:
-the air pipe of the exhaust gas recirculation bypass
control solenoid valve,
-the exhaust gas recirculation solenoid valve con-
nector.
II - FINAL OPERATION
a Refit:
-the exhaust gas recirculation rigid pipes (see 14A,
Antipollution, Exhaust gas recirculation rigid
pipe: Removal - Refitting, page 14A-30) ,
-the intercooler air inlet pipe (see 12B, Turbochar-
ging, Intercooler air inlet pipe: Removal - Refit-
ting, page 12B-41) ,
-the battery tray (see Battery tray: Removal - Re-
fitting) (80A, Battery),
-the battery (see Battery : Removal - Refitting)
(80A, Battery),
-the scoop under the scuttle panel grille (see Scoop
under scuttle panel grille: Removal - Refitting)
(56A, Exterior equipment),
-the scuttle panel grille (see Scuttle panel grille:
Removal - Refitting) (56A, Exterior equipment),
-the windscreen wiper arms (see Windscreen wi-
per arm: Removal - Refitting) (85A, Wiping -
Washing),
-the engine undertray,
-the engine cover.
a Bleed the cooling system (see 19A, Cooling, Coo-
ling circuit: Draining - Refilling, page 19A-17) .
