17A-2
IGNITION
Coils Removal - Refitting
F4R
17A
REFITTING
I - REFITTING PREPARATION OPERATION
a Apply a bead of FLUOSTAR 2L grease (see Vehi-
cle: Parts and ingredients for the repairwork)
(04B, Consumables - Products) 2 mm in diameter at
(4) on the internal perimeter of the high tension caps
on the four coils.
II - REFITTING OPERATION FOR PARTS
CONCERNED
a Refit the coils.
a Position the camshaft dephaser solenoid valve.
a Torque tighten the coil bolts (12 N.m).
a Connect:
-the camshaft dephaser solenoid valve connector,
-the coil connectors.
III - FINAL OPERATION
a Refit the engine cover.
106443
