19C-13
TANK
Fuel tank: Removal - Refitting
19C
a Refit:
-the central heat shield,
-the centre heat shield clips,
-the connector pipe (see 19B, Exhaust, Connector
pipe: Removal - Refitting, page 19B-35) ,
-the silencer (see 19B, Exhaust, Silencer: Remo-
val - Refitting, page 19B-40) .
a Connect:
-the fuel pipe unions on the fuel level sensor modu-
le,
-the fuel level sensor module connector.
a Connect:
-the fuel pipe union on the fuel level sensor module,
-the fuel level sensor module connectors.
a Clip on the fuel level sensor module connector.
a Refit:
-the plastic blanking cover of the passenger com-
partment,
-the subframe panel.
a Refit the rear bench seat.
a Connect the battery (see Battery : Removal - Refit-
ting) (80A, Battery).
F9Q or K9K
F4R or K4M
