PG-FP5 CHAPTER 8 USAGE COMMUNICATION COMMANDS
R20UT0008EJ0400 Rev. 4.00 Page 178 of 240
Jul 15, 2010
8.5.12 prg command
Executes [Program] command.
Input format
'prg'
Description of the function
Executes a similar function to the programming GUI [Device] menu -> [Program] command.
Example of usage
Command Status Status LED Message display Screen output
Display while executing the command
[Chip mode]
BUSY
Program Chip
Addr: 0x000000
Program Chip:
10%
20%
:
100%
Display while executing the command
[Block mode]
BUSY
Program Block
Addr: 0x000000
Program Block sss to eee:
10%
20%
:
100%
or
Program Block 000:
10%
20%
:
100%
Program Block 001:
:
Program Block eee:
Display while executing the command
[Area mode]
BUSY
Program Area
Addr: 0x000000
Program Area 000:
10%
20%
:
100%
Program Area 001:
:
Program Area eee:
Display after executing the command
[When completed normally]
PASS
Returns to the display
before executing the
command.
PASS
Program operation finished.
prg
Display after executing the command
[When terminated abnormally]
ERROR
ERROR: xxx
xxxxxxxxxxxxxxxx
ERROR(Exxx): <text>
Program operation finished.
