Renesas PG-FP5 User Manual

PG-FP5 CHAPTER 9 CONNECTORS AND CABLES
R20UT0008EJ0400 Rev. 4.00 Page 184 of 240
Jul 15, 2010
CHAPTER 9 CONNECTORS AND CABLES
9.1 Power Supply Connector
The power supply connector is laid out on the host interface side of the FP5.
Figure 9-1. Power Supply Connector <FP5 Host Interface Side>
Figure 9-2. Power Supply Connector Pin Assignment
+
−
Caution Do not connect an AC adapter other than the one for the PG-FP5 to the power supply connecter.
Power supply connector
<R>
