Renesas PG-FP5 User Manual

PG-FP5 CHAPTER 8 USAGE COMMUNICATION COMMANDS
R20UT0008EJ0400 Rev. 4.00 Page 159 of 240
Jul 15, 2010
8.4.15 res command
Resets FP5.
Input format
'res'
Description of the function
Executes a function similar to the programming GUI [Programmer] menu -> [Reset] command.
Example of usage
Command Screen output
res
FFFFFFF PPPPP 555555
F P P 5
F P P 5
F P P 55555
FFFFF PPPPP 5
F P 5
F P 5
F P 5 5
F P 5555
Firmware Version Vx.xx
Board H/W Vx, FPGA Vx
Serial No.:xxxxxxxxxx
Standard mode unsecured
8.4.16 security command
Confirms the security state that can be set by the [FP5 Manager] command.
Input format
'security'
Description of the function
Confirms the security state that can be set by the [FP5 Manager] command.
Example of usage
Command Screen output
security
[When password-protection is valid]
Security state is: Locked
Authorization procedure is: Password
[When password-protection is invalid]
Security state is: Inactive
Authorization procedure is: Undefined
