PG-FP5 CHAPTER 6 USAGE IN STANDALONE MODE
R20UT0008EJ0400 Rev. 4.00 Page 126 of 240
Jul 15, 2010
6.3 Standalone Operation Menu
In standalone mode, the programming environment of the target device can be checked and then programs can be
written by using the commands explained in this section.
6.3.1 [Commands] menu
The [Commands] menu provides various commands required for programming the target device. Select a command
from this menu and press the ENTER button; the FP5 will then execute the command for the target device, based on the
settings downloaded to the valid programming area. For details on command execution, refer to 4.3.3 [Device] menu.
Table 6-1. [Commands] Menu (1/2)
Main Menu Submenu Description
[E.P. >]
Pressing the ENTER button executes the [A
utoprocedure(E.P.)] command.
[Program >]
Pressing the ENTER button executes the [P
rogram] command.
[Erase >]
Pressing the ENTER button executes the [E
rase] command.
[Verify >]
Pressing the ENTER button executes the [V
erify] command.
[Set Security >]
Pressing the ENTER button executes the [Set Security
] command.
[Commands >]
[Checksum >]
Pressing the ENTER button executes the [Checksum
] command. The checksum
value read from the target device is displayed in the message display.
<Display example>
Checksum: 623E
Or, the cross referencing results will be displayed if the FP5 Manager [Checksum
comparison] is enabled.
<Display example>
Checksum: 623E
Compare: PASS
The following will be displayed when a PR5 file that supports data flash is
downloaded.
<Display example>
Code Flash sum:
xxxx -> Enter
Click the ENTER button.
Data Flash sum:
yyyy -> Enter
Click the ENTER button.
Total sum:
zzzz -> Enter
Click the ENTER button.
Check sum:
Compare: PASS
