Renesas PG-FP5 User Manual

PG-FP5 CHAPTER 8 USAGE COMMUNICATION COMMANDS
R20UT0008EJ0400 Rev. 4.00 Page 183 of 240
Jul 15, 2010
8.5.17 vrf command
Executes [Verify] command.
Input format
'vrf'
Description of the function
Executes a similar function to the programming GUI [Device] menu -> [Verify] command.
Example of usage
Command Status Status LED Message display Screen output
Display while executing the command
[Chip mode]
BUSY
Verify Chip
Addr: 0x000000
Verify Chip:
10%
20%
:
100%
Display while executing the command
[Block mode]
BUSY
Verify Block
Addr: 0x000000
Verify Block sss to eee:
10%
20%
:
100%
or
Verify Block 000:
10%
20%
:
100%
Verify Block 001:
:
Verify Block eee:
Display while executing the command
[Area mode]
BUSY
Verify Area
Addr: 0x000000
Verify Area 000:
10%
20%
:
100%
Verify Area 001:
:
Verify Area eee:
Display after executing the command
[When completed normally]
PASS
Returns to the display
before executing the
command.
PASS
Verify operation finished.
vrf
Display after executing the command
[When terminated abnormally]
ERROR
ERROR: xxx
xxxxxxxxxxxxxxxx
ERROR(Exxx): <text>
Verify operation finished.
